Power Supply Assembly 5372507-3-R

5372507-3-R
Computed Tomography (CT)
BRIVO CT385
GE HealthCare Colombia S.A.S
GE HealthCare
Añadir a la lista de deseos
Iniciar sesión y agregar al carrito
Iniciar sesión y agregar al carrito
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


El artículo no está disponible en inventario con las cantidades seleccionadas. Por favor actualice la cantidad para continuar.

Características

  • Accepts universal input of 85-264 VAC
  • Reverse voltage protection
  • PMBus® compliant
  • Intelligent fan (speed control/fault status)

Otras opciones de compra


Descripción del producto

This is a specially designed low voltage power supply module which converts AC input voltage into DC voltage. It is a configurable AC-DC power supply with outputs of a +12 VDC, three +48 VDC and two +24 VDC. The power supply accepts universal input of 85-264 VAC or 120-350 VDC. The power supply relies upon forced air cooling for heat dissipation which allows it to work reliably over a wide range of temperatures starting from -40 °C to 70 °C. This six outputs DC power supply is packaged in a industry standard case and maintains very low earth leakage currents, making them suitable for modern medical applications. The power supply is featured with reverse protection and fuse protection. This power supply is compatible to be used with GE's Discovery CT590, Optima CT580 and Brivo CT385 Computed Tomography (CT) Systems. 5372507-3-R

  • Características adicionales

    • uP controlled PFC input with active inrush protection
    • Industrial temp range (-40 ºC to 70 ºC)
    • Full Medical EN60601 approval
    • Terminal block input
    • Low profile 1U size

    Productos compatibles

    Brivo 385

    Brivo 385
