Cradle Driver Cable Positioning Global Table

5314448-2
5314448-3
Computed Tomography (CT)
Lightspeed VCT 32
GE HealthCare Colombia S.A.S
GE HealthCare
Añadir a la lista de deseos
Iniciar sesión y agregar al carrito
Iniciar sesión y agregar al carrito
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


El artículo no está disponible en inventario con las cantidades seleccionadas. Por favor actualice la cantidad para continuar.

Características

  • Good Conductivity
  • High Transfer Speed
  • Easy to Connect Connectors
  • EMI/RFI Shielding

Descripción del producto

This cable comprises of a 5 position-1 row female connector at one end and a 4 position-1 row female connector at the other end, connected using a 1530 mm long cable having 4 x 20 AWG, shielded copper conductors which offers good conductivity and high transfer speed. This cable is properly shielded using copper shielding which offers good electromagnetic insulation and high mechanical strength. A 28 mm long ferrite bead with 217 ohms impedance is also provided in the cable which offers very good EMI/RFI shielding. This ferrite core is covered with heat shrink tube and secured the by tie-wraps at both ends. The cable assembly is properly insulated using poly-vinyl chloride jacket which is heat resistant, flame retardant, offers flexibility and have shock absorbing property. For ease of identification the connectors and cable assembly comes with pre-labeled informations regarding the connecting ends. This cable assembly is used to interface the cradle driver of GT2000 N9, GT1700 N9 table assembly of the GE's Computed Tomography (CT) Systems.

  • Características adicionales

    • With Proper Insulation
    • Reliable Operation
    • Long Service Life
    • RoHS Compliant

    Productos compatibles

    Optima 660

    Optima 660

    Optima 540

    Optima 540

    Revolution EVO

    Revolution EVO

    Lightspeed RT Xtra

    Lightspeed RT Xtra

    Lightspeed RT

    Lightspeed RT

    Discovery 750 HD

    Discovery 750 HD

    Discovery ST

    Discovery ST

    Discovery ST (64 Slice)

    Discovery ST (64 Slice)

    Discovery ST (128 Slice)

    Discovery ST (128 Slice)

    Artículo equivalente:

    Tenemos las siguientes piezas equivalentes disponibles para usted. Estas son piezas de reemplazo compatibles. Estas piezas sin un hipervínculo se enumeran solo como referencia y no están disponibles para su compra en línea. Para obtener información adicional, comuníquese con el servicio al cliente

    Artículo equivalenteDetalles de parte
    5314448-3

    New Cradle Driver Cable Positioning GT
