8-port Unmanaged Ethernet Switch 5183308-2-H

5183308-2-H
Interventional Image Guided Systems
Other Interventional Image Guided Systems
GE HealthCare Colombia S.A.S
GE HealthCare
Añadir a la lista de deseos
Iniciar sesión y agregar al carrito
Iniciar sesión y agregar al carrito
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


El artículo no está disponible en inventario con las cantidades seleccionadas. Por favor actualice la cantidad para continuar.

Características

  • Provides 8 Fast Ethernet ports with Auto MDI/MDI-X
  • Supports 10/100 Mbps Auto-Negotiation
  • Provides compact size with DIN-rail/Wall mount, and IP30 metal mechanism
  • Supports redundant 12 ~ 48 VDC power input and P-Fail relay

Otras opciones de compra


Descripción del producto

This Ethernet Switch includes 8 unmanaged full auto-negotiating 10/100 ports. It is a +12 ~ 48 VDC redundant power input design, and is secured with a double protection mechanism: Power Polarity Reverse Protection and Overload Current Resetable Fuse. The former tolerates reverse power switching while the later secures the system from overload currents. As the power supply turns normal, it automatically get back to work. Each port has 2 LED’s to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators. It comes with a compact metal IP30 rated housing to protect against dusty industrial environments. The easy to read top panel LEDs show ongoing switch status and simplify troubleshooting. The switch can be used with GE's INNOVA 2121 and INNOVA 3131 Interventional Image Guided Systems. 5183308-2-H

  • Características adicionales

    • Supports wide operating temperatures from -40 to 75 °C
    • Easy installation and high performance
