Twin Gradient Switch Box 2253466-R
| 2253466-R | |
| Resonancia Magnética | |
| 1.5T Signa Excite HD | |
| GE HealthCare Colombia S.A.S | |
| GE HealthCare | |
Añadir a la lista de deseos
Iniciar sesión y agregar al carrito
Please select date
Second Opinion Approval Needed
Enter your approval number and submit to add item(s) to cart.
Approval Number
Please enter approval number
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.
Second Opinion Approval Needed
Select your approver's name and submit to add item(s) to your cart
Approver Name
Please Select Approver Name
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.
El artículo no está disponible en inventario con las cantidades seleccionadas. Por favor actualice la cantidad para continuar.
Características
- No Manual Field Calibration Required
- Mean Time Before Failure of more than 20000 Hours
- With Safety Labels
- EMC Design
Descripción del producto
The Gradient Switch is part of the Twin-Gradient GEMINI project. Its function is to switch between the twin Coils (WB= Whole Body and ZM= ZooM gradient) under the command of the Operator or the Host Computer. The switching is done mechanically by Contactors. These contactors can carry currents up to 400A and have insulation of 1500V. There are 6 contractors: 3 for WB and 3 for ZM. The Commands are sent through Opto-Couplers and SSR (Solid State Relays) to keep good isolation between Commands and the Gradient currents. The assembly is installed in a special cabinet, on the way from the Gradient Amplifier to the Gradient Filter (on the Penetration Panel). The Unit in its communication to the GP (Gradient Processor) also send the Contactors Status and Diagnostic information for Faults. The whole Unit is designed to be mounted in a Rack 19 inches Standard : 6U Height, 36 inches depth. This Twin Gradient Switch is compatible for use with GE's Signa 3.0T HDxt and Signa 1.5T HDxT Magnetic Resonance Imaging (MRI) Systems. 2253466-R
Características adicionales
- Reliable Operation
- Built-in LED Indicators
- Fuse Protected
- 19 Inches Rack Mount Unit
