External Radial Mount 0.188 Shaft Diameter 0.123 Free Dia

46-220277P27
Magnetic Resonance Imaging
GE HealthCare Colombia S.A.S.
GE HealthCare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Sorry, this item is not in stock with the quantity you selected. Please update the quantity to continue.

Features

  • Good Corrosion resistance
  • Rugged
  • For one time use only
  • Beryllium Copper Material

Product Overview

This external retaining ring comes in a shape of english alphabhet "E" thus commonly known as E-Ring, basically it is a type of fastener that holds the components or assemblies onto a shaft or in a housing/bore when installed. These E-Rings are typically installed on a externally machined groove of the shaft, the rings have no lug holes and must be installed using applicators and once installed they act as a shoulder or collar which retains the specific component or assembly in place. The "E" shape exert a pre-load on an assembly when installed in the groove. This also takes up the end-play and acts like a spring, which keeps the assembly in compression. The Beryllium Copper material of this ring is non-magnetic which makes it suitable for use in the assemblies of Magnetic Resonance Imaging Systems. This E-Ring will be shipped in suitable packaging to provide adequate protection during transit.

  • Additional Features

    • Meant for external installation on shaft grooves
    • Redues end play
    • Durable
    • Non-Magnetic

    Compatible Products

    Brivo 355

    Brivo 355

    Discovery 750 Surgical 3.0T

    Discovery 750 Surgical 3.0T

    Discovery 750w GEM 3.-T

    Discovery 750w GEM 3.-T

    Discovery 750 3.0T WU_0755

    Discovery 750 3.0T WU_0755

    Optima 360 1.5T

    Optima 360 1.5T

    Signa Excite 1.5T

    Signa Excite 1.5T

    Signa HD 1.5T

    Signa HD 1.5T

    Signa HD 3.0T

    Signa HD 3.0T

    Signa HDe 1.5T

    Signa HDe 1.5T

    Signa HDx 1.5T

    Signa HDx 1.5T

    Signa HDx 3.0T

    Signa HDx 3.0T

    Signa HDxt 1.5T

    Signa HDxt 1.5T

    Signa HDxt 3.0T

    Signa HDxt 3.0T
